D511Pro
ATRONTEC
D511Pro Industrial Process Control Weighing Indicator
– D511Pro is a high precision Industrial Process Weighing Controller. This weighing controller has a variety of communication interfaces with high reliability which is typical for complicated and harsh environment.
– - DIN Rail Configuration: Basic application,1xRS232/RS485,MODBUS-RTU,EtherNet/IP(2xLAN ports),24VDC
Weighing Indicator Overviews:
7-bit LED green display
Supports 1 analog scale input, with up to 12 load cells
Standard with serial port x 1 (RS232/485), 2 LAN ports, and 1 high precision weighing AD
Standard supports MODBUS-RTU
Optional PLC communication interface
PROFIBUS-DP (Siemens PLC)
CC-link IE FB (Mitsubishi PLC)
EtherCAT (HIAS PLC)
EtherNet/IP (dual LAN ports, built-in switch, rockwell PLC, Delta PLC)
Optional I/O (input/output)
In x 4 / MOS Out x 6
Multiple calibration modes
Supports up to 5-point code-breaking calibration
Ccalibration without weights
Remote calibration through PLC communication interface
Calibration with material
Application supports
Basic weighing version
Supports dual-speed preset point control and 8 simple comparison outputs
Lower/upper limit material level detection
Working Power
Supports AC 85-264VAC or DC 24VDC
The maximum power consumption of the complete machine is less than 6W
Weighing Indicator Specifications:
| Accuracy Class | III |
| Division | up to 15,000 display division, 7500e(Approved) |
| Display | 7-bit green LED display |
| Update Speed | 200Hz weight updating spee |
| Keypad Lock | support |
| Calibration Modes | |
| Calibration | 2-point/3-point with testing weight or no testing(CalFree) |
Calibration parameter viewing and manual input recovery function | |
Remote calibration function | |
| Load Cell | |
| Exciting Voltage | 5V DC, 0~20mV input signal range |
| Load Cell Number | 8 x 350Ω |
| Connect Type | 4- wired or 6-wired |
| Communication I/F | |
| Serial Port | one RS232/485 serial port |
| EtherNET/IP | connect Rockwell, Delta and other PLCs |
| EtherCAT | connect Inovance PLC |
| PROFINET | connect Siemens PLC |
| CC-LINK | CC-LINK IE Field Basic connect Mitsubishi PLC |
| Application PAC | |
| Basic Weighing | Dual speed control preset point, automatic advance correction function, 200Hz comparison speed |
