D520
ATRONTEC
D520 Multifunctional Industrial Process Weighing Controller
– D520 is a high precision Industrial Process Weighing Controller. This weighing controller has a variety of field-bus communication with high reliability which is typical for complicated and harsh environment.
– Therefore D520 can be used in chemical and hazardous industries for weighing purpose,packaging engineering,batching control system,filling system solution,etc…
Weighing Indicator Overviews:
2.7-inch OLED dot matrix graphic display,
Supports 1 analog scale input, with a maximum of 12 load cel
Standard serial ports x 2 RS232 + RS232/485, or serial ports x 2 RS232 + RS485 with one LAN port
Standard supports MODBUS-RTU, MODBUS-TCP (only supported by the ethernet version)
Optional PLC communication interface
PROFIBUS-DP (Siemens PLC)
CC-Tink (Mitsubishi PLC)
scale x 1, 4-20mA (16-bit precision DAC)
scales x 2, 4-20mA (16-bit precision DAC)
PROFINET (dual LAN ports, built-in switch, Siemens PLC)
EtherNet/IP (dual LAN ports, built-in switch, Rockwell PLC, Delta PLC)
Optional I/O (input/output)
In x 8 / OC Out x 12
In x 8 / Relay Out x 12
Multiple calibration modes
Supports up to 5-point code-breaking calibration • calibration without weights
Remote calibration through PLC communication interface
Application supports
Basic weighing version/bagging version/checkweighing version/filling version/batching version
The working power supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the complete machine is less than 6W
Weighing Indicator Specifications:
| Accuracy Class | III |
| CMC Approval | 150,000d, 6000e(Approved) |
| Display | 128×64 green OLED dot matrix graph display |
| Update Speed | 60ms |
| Status Display | Tare,Net,Motion,Zero,Unit,PLC |
| 20 Keys | F key,Tare/Clear,Zero,Print,10 digit keys |
| Power On/Off | None |
| Keypad Lock | Can be locked via local input or remote communication(MODBUS-RTU,MODBUS-TCP,PROFIBUS-DP) |
| Scale Basic Functiona | |
| Calibration | 2-point with testing weight or no testing(CalFree) |
| Filter | 5-step |
| Scale Process | Tare,Zero,Auto Zero,Motion, Auto Tare, Auto Clear,Auto Print |
| Inputs | Option 8 Inputs,Can be assigned remote inputs for remote host(PLC or DCS) |
| Outputs | Option 12 Outputs,Can be assigned remote outputs for remote host(PLC or DCS) |
| Others | Display gross weight, net weight, rate |
| Load Cell | |
| Exciting Voltage | 5V DC, max 150mA |
| Load Cell Number | Max 12 x 350Ω |
| Connect Type | 4- wired or 6-wired , Cable:274mR/m2 |
| Communication I/F | |
| Serial Port | 2 ports:COM1-RS232, COM2-RS232/485 |
| MODBUS-RTU,Continuous output weight,Demand input & output | |
| PROFINET | Connect to Siemens PLC,report integer weight data & floating weight data |
| EtherNET/IP | Connect to Rockwall PLC,report integer weight data & floating weight data |
| MODBUS-RTU | Support, Integer & Floating weight data |
| LAN | 100M,TCP,UDP,MODBUS-TCP |
| Analog Output | two chanel 4-20mA output, 16-bit DAC |
| PROFIBUS-DP | Integer and floating data output,100Hz updating speed |
| 3GSD inside,totally compatible to PANTHER & IND131/331 | |
| CC-LINK | for Mitsubishi PLC,totally compatible to PANTHER & IND131/331 |
| Application PAC | |
| Basic Weighing | 2-speed target control:Filling & dumping control(Over/Under/Over) |
| Batching PAC | Up to 8 materials, Sequence Filling/ Random Filling |
| Checking Weighing PAC | Both photoelectricity and weight input are available for checking weighing,Support classify output:up to 8 ranges |
| Bagging PAC | Weigh-Hopper Bagging/No-Weigh-Hopper Bagging/In-continuous-weighing totalization Bagging |
| Filling PAC | No-Gun-Control Filling / Gun-Control Filling |
