Stainless Steel Waterproof Weighing Indicator with Red Led Display

This stainless steel weighing indicator is specially designed for waterproof platform scales which are used in harsh and washdown environments. This weighing indicator has sturdy structure and high accuracy,it's stable weighing function and reliable perfomance win high reputation in global weighing market.
Weight indicator:
Protection Level:
Serial Interface:
  • XK3108A

Stainless Steel Waterproof Weighing Indicator with Red Led Display

Waterproof Weighing Indicator Features:

- IP68 class waterproof and dustproof  design for moist, corrosion and other special environment

- Stainless steel casing

- Super large LED display screen

- Patented joint for indicator that is easy to use and reliable

- Measurement unit switch function(g, kg, lb. lb)

- Set-value alarm function

- Counting function

- Accumulating function

- Voltage indicate and low voltage alarm function

Waterproof Weighing Indicator Specifications:

- Capacity: 15,30,60,150,300,600,1500,3000kg

- Resolution selectable: 3000,6000,15000,3000

- Display mode: 25mm LED Display

- Housing: Mirror finished SUS304 stainless steel

- Operation temperature: -10°C - +40°C(14F-104F)

- Power supply: AC110V/230V(±10%) or DC6V4Ah rechargeable battery

- Working hours without extent power supply: 80h

- Optional function: RS232 interface,weight checking,output interface,stainless steel instrument joint

Waterproof Weighing Indicator Pameters:

Resolution selectable3000,6000,15000,30000
Display mode25mm   LED with white backlight
Housing materialMirror   finished SU304 stainless steel
Operation temperature-10°C   - +40°C(14F-104F)
Power supplyAC110V/230V(±10%)   or DC6V4Ah rechargeable battery
Working hours without extenal power supply80h
Optional functionRS232   interface,weight checking output interface,stainless steel instrument joint
Housing dimensions214*138*99mm

Preparation Before Use

  • This weighing indicator must be used on a flat ground, not on a slope or a place with relatively large vibration.

  • Do not use it in a place where the temperature changes greatly. When using it, try to avoid using it at the environment with the temperature too high or too low.


  • Check and make sure the weight of objects to be weighed within the maximum capacity of the electronic scale. If the number displayed on the weight indicator is abnormal, maybe it means that electronic scale is overweight, and the item should be removed in time, do not keep placing it on it.

  • Don't move or shake the electronic scale when things are put on it. It will display inaccurate weight during vibration and also damage the electronic scale.

Proper Maintenance

  • Ensure that the surface of the waterproof electronic scale is clean, try not to have water stains, oil stains and oil stains on the surface for a long time.

  • Put the waterproof scale in a safe place, so as to avoid unnecessary scratching and cracking of the surface. Severe collisions will also cause displacement of parts and cause electronic scale failure.

  • Don't disassembly the internal parts of the waterproof scale casually. Necessary repairs need to be under the guidance of relevant technical personnel or users have certain qualifications. Improve maintenance knowledge to prevent the fault from expanding.

  • Check the battery regularly. Open the cover of the battery to see if the battery is damaged. If the outside is damaged, replace it in time even if it doesn't affect the use temporarily. Check whether the lead wire is intact to prevent short circuit,battery damage and electronic scale circuit.

Our products owned a credible quality as well as good reputation in the market.
